Scantool Hardware Support List

USB Devices Supported

• OBDlink SX

Bluetooth Devices Supported

• OBDlink LX
• OBDlink MX


PID Support List

Actual Parameter Data is Vehicle Specific. The software will only show those parameters supported by the vehicle.

PID / Description

00 / Supported PIDs 01 to 1F
01 / Number of DTCs , MIL Status and available OB Tests
02 / Freeze frame DTC
03 / Fuel system status
04 / Calculated Engine load
05 / Engine coolant Temperature
06 / Short-term fuel % trim bank 1
07 / Long-term fuel % trim bank 1
08 / Short-term fuel % trim bank 2
09 / Long-term fuel % trim bank 2
0A / Fuel pressure
0B / Intake manifold pressure
0C / Engine RPM
0D / Vehicle speed
0E / Timing advance on cylinder 1
0F / Intake air temperature
10 / Mass air flow rate
11 / Throttle position
12 / Status air status
13 / O2 sensor present
14 / Oxygen sensor volts bank 1 sensor 1
15 / Oxygen sensor volts bank 1 sensor 2
16 / Oxygen sensor volts bank 1 sensor 3
17 / Oxygen sensor volts bank 1 sensor 4
18 / Oxygen sensor volts bank 2 sensor 1
19 / Oxygen sensor volts bank 2 sensor 2
1A / Oxygen sensor volts bank 2 sensor 3
1B / Oxygen sensor volts bank 2 sensor 4
1C / OBD standard
1D / O2 sensor present 2
1E / Auxiliary input status
1F / Run time since engine start
20 / Supported PIDs 21 to 3F
21 / Distance travelled with MIL on
22 / Relative fuel rail pressure
23 / Fuel rail pressure (Diesel)
24 / O2 sensor bank 1, sensor 1 (lambda volts)
25 / O2 sensor bank 1, sensor 2 (lambda volts)
26 / O2 sensor bank 1, sensor 3 (lambda volts)
27 / O2 sensor bank 1, sensor 4 (lambda volts)
28 / O2 sensor bank 2, sensor 1 (lambda volts)
29 / O2 sensor bank 2, sensor 2 (lambda volts)
2A / O2 sensor bank 2, sensor 3 (lambda volts)
2B / O2 sensor bank 2, sensor 4 (lambda volts)
2C / Commanded EGR
2D / EGR error
2E / Commanded evaporative purge
2F / Fuel level
30 / Number of warmups since DTCs cleared
31 / Distance travelled since DTCs cleared.
32 / Evaporation system vapour pressure
33 / Barometric pressure
34 / O2 sensor bank 1, sensor 1 (lambda current)
35 / O2 sensor bank 1, sensor 2 (lambda current)
36 / O2 sensor bank 1, sensor 3 (lambda current)
37 / O2 sensor bank 1, sensor 4 (lambda current)
38 / O2 sensor bank 2, sensor 1 (lambda current)
39 / O2 sensor bank 2, sensor 2 (lambda current)
3A / O2 sensor bank 2, sensor 3 (lambda current)
3B / O2 sensor bank 2, sensor 4 (lambda current)
3C / Catalyst temperature bank 1, sensor 1
3D / Catalyst temperature bank 2, sensor 1
3E / Catalyst temperature bank 1, sensor 2
3F / Catalyst temperature bank 2, sensor 1
40 / Supported PIDs 41 to 5F
42 / Control module voltage
44 / Commanded equivalence ratio
45 / Relative throttle position
46 / Ambient air temperature
47 / Absolute throttle position B
48 / Absolute throttle position C
49 / Accelerator pedal position D
4A / Accelerator pedal position E
4B / Accelerator pedal position F
4C / Commanded throttle actuator
4D / Engine run time since MIL on
4E / Engine run time since DTCs cleared
4F / External test 1 configuration information
50 / External test 2 configuration information
51 / Fuel type
52 / Percentage alcohol mix
54 / Evaporative system vapour pressure
59 / Absolute fuel rail pressure
5A / Relative accelerator pedal position
5B / Hybrid battery pack remaining life
5C / Engine oil temperature
5D / Fuel injection timing
5E / Fuel rate
5F / Emission Requirements
